Edgecore Swicth รุ่น ECS2100-10P
รายละเอียดโดยย่อ
ECS2100-10P
ECS2100-10P
- ECS2100-10P เป็น Web Smart Pro Switch รองรับ 8 x GE PoE ports + 2 GE SFP uplink ports with 1 RJ45 Console port and Fanless design. งบประมาณสูงสุดของ PoE 125 วัตต์.
ข้อมูลทางเทคนิค
| Model | ECS2100-10P |
| RJ-45 10/100/1000 Ports | 8 |
| SFP or SFP+ Uplink Ports | 2 (1G) |
| PoE Ports | 8 |
| Console Port | 1 |
| Switching Capacity | 20 Gbps |
| Forwarding Rate | 14.9 Mpps |
| Flash Memory | 32 MB |
| DRAM | 256 MB |
| Packet Buffer | 4.1 Mbits |
| MAC Address Table | 8 K |
| Jumbo Frames | 10 K |
| MTBF | 865,820 hrs |
| Heat Dissipation | 545.933 (Btu/H) |
| Acoustic Noise | 0 dB (A) |
| 100-240 VAC, 50-60 Hz | 0 |
| Max System Power Consumption (Watts) | 160 W |
| IEEE 802.3af/802.3at | 0 |
| PoE Power Budget | 125 W |
| PoE Timer | 0 |
| Rack Space | 13" |
| Form Factor | Rackmount |
| Dimension (W x D x H) | 33 x 20.4 x 4.26 cm (12.9 x 8 x 1.67 in) |
| Weight | 2.4 kg (5.34 lb) |
| Operating Temperature | 0 ~ 40ºC |
| Storage Temperature | -40 ~ 70ºC |
| Altitude | 3000 m |
| Operating Humidity (non-condensing) | 10% to 90% |
| Storage Temperature (non-condensing) | 10% to 90% |
| WEEE | 0 |
| RoHS | 0 |
